5-16 Monitoring and Modifying Data
Publication 1747-6.1
The display appears as shown below:
How to Change Bit Status at the Bit Level
You may also change the on/off status of a bit, with a Bit file word
displayed at the bit level.
For example, to change the status of bit B3:2/3 to Off:
1. Display the address to the bit level:
Press
[0].
2. The Off state of the bit displays, and a blinking cursor appears
over the bit:
3. To change the state of the bit in memory:
Press
4. The zero remains on the display and the cursor disappears.
0000000000101000
B3:10
B3:2/3
.................1..
B3:2/3
.................0..
