Quick Recall Functions 6-3

Publication 1747-6.1

Clearing Quick Recall

Functions

To erase Quick Recall Function F(1), make sure that no data file

address is displayed (otherwise you will re-define the Recall Function

or Macro):

1. Configure the module for the Modify mode.

2. With either Ready screen displayed:

Press

3. The LCD displays the following for three seconds:

4. The display returns to the previous screen.

5. You may now perform any of the module functions.

RDY> 4 RRUN

Macro 1 Cleared
