Chapter 4 Module Configuration, Output, and Input Data
Table 17 - Input Array - L23E Packaged Controller Enbedded HSC
Word Bit Function
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
0
Not used Z1 B1 A1 Z0 B0 A0 Input State
1 Out
15
Out
14
Out
13
Out
12
Out
11
Out
10
Out
9
Out
8
Out
7
Out
6
Out
5
Out
4
Out
3
Out
2
Out
1
Out
0
DataEcho
2 BadRangeLimit 30 BadRangeCtrNum30 ERR UBS MCfg
OverCurFdbck
Output030
Status Flags
3 R3 R2 R1 R0
Not used Range Active
4 PresentCount_0 PresentCount_0
5
6 StoredValue_0 StoredValue_0
7
8
Not used Not used
9
10
Not used Not used
11
12
Not used C0PW Not
used
Not
used
BD
W
REZ CUdf COvf Counter 0 Status
Flags
13
Not used Not used
14 PresentCount_1 PresentCount_1
15
16 StoredValue_1 StoredValue_1
17
18
Not used Not used
19
20
Not used Not used
21
22
Not used C1PW Not
used
CNE BD
W
REZ CUdf COvf Counter 1 Status
Flags
23
Not used Not used
24 PresentCount_2 PresentCount_2
25
26
Not used Not used
27
28
Not used C2PW RV IC BD
W
CUdf COvf Counter 2 Status
Flags
29
Not used Not used
30 PresentCount_3 PresentCount_3
31
