104 Rockwell Automation Publication 1769-UM006E-EN-P - July 2013
Chapter 4 Module Configuration, Output, and Input Data
Current Count (Ctr[n].CurrentCount)
This is the 32-bit count value from the counter.
Stored Count (Ctr[n].StoredCount)
This is the last stored 32-bit value from counter (n). The count value is stored
depending on the CtrnConfig.StorageMode and Zn inputs.
When a storage event occurs, the Ctr[n].RisingEdgeZ bit is set, indicating that
the value is new. If more than one Zn occurs before the Ctr[n].RisingEdgeZ bit is
reset (using the CtrnResetRisingEdgeZ bit), the Ctr[n].StoredCount word will
contain only the last Ctr[n].StoredCount value. There is no indication that the
data has been overwritten.
Input Array Words 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
4 Counter 0 Current Count Ctr[0].CurrentCount
5
14 Counter 1 Current Count Ctr[1].CurrentCount
15
24 Counter 2 Current Count Ctr[2].CurrentCount
25
30 Counter 3 Current Count Ctr[3].CurrentCount
31
Input Array Words 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
6 Counter 0 Stored Count Ctr[0].StoredCount
7
16 Counter 1 Stored Count Ctr[1].StoredCount
17
