108 Rockwell Automation Publication 1769-UM006E-EN-P - July 2013
Chapter 4 Module Configuration, Output, and Input Data
CnPW - Counter Preset Warning (Ctr[0].PresetWarning to
Ctr[3]
.PresetWarning)
This bit is set when Ctr[n].CurrentCount has been forced by the module to the
CtrnPreset value. This will happen when a configuration array is accepted, which
sets the following:
• CtrnMinCount > Ctr[n].CurrentCount
or
• CtrnMaxCount < Ctr[n].CurrentCount.
This bit is reset by a 0 to 1 transition of the CtrnResetCtrPresetWarning bit in the
output array.
TIP
You must manually reset CnPW, COvf, CUdf and REZ (but not IDW, RV or
IC) to enable them to be set again.
