126 Rockwell Automation Publication 1769-UM006E-EN-P - July 2013
Appendix A Specifications
Throughput and Timing
Table 29 - Certifications - 1769-HSC
(1)
Certification
(2)
1769-HSC
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584
c-UL-us UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S. and Canada.
See UL File E321922
CE European Union 2004/108/EC EMC Directive, compliant with the following:
• EN 61000-6-2; Industrial Immunity
• EN 61000-6-4; Industrial Emissions
• EN 61131-2; Programmable Controllers (Clause 8, ZoneA&B)
C-Tick Australian Radiocommunications Act, compliant with AS/NZS CISPR 11; Industrial Emissions
(1) When product is marked.
(2) See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification details.
Operation Description Timing
Input file update time The delay between the time the module receives a pulse and when the Compact bus
count value is updated.
500 µs, max
Output turn-on time The time it takes for the real output to reach 90% output voltage after commanded by
the module, not including processor scan time.
400 µs, max
Output turn-off time The time it takes for the real output to reach 10% output voltage after commanded by
the module, not including the processor scan time.
200 µs, max
Rate accuracy The accuracy of the reported rate as compared to actual input rate in the equation:
reported rate/actual input rate.
Depends on frequency.
See
Rate Accuracy on
page 127.
