132 Rockwell Automation Publication 1769-UM006E-EN-P - July 2013
Appendix B Program a 1769-HSC Module, CompactLogix Controller, and 845F Incremental Encoder with RSLogix 5000 Software
845F Encoder Wiring to the
1769-HSC Module
Scope
These steps are used in this example.
1. Add the 1769-HSC module into a CompactLogix system by using
RSLogix 5000 software.
2. Configure the 1769-HSC module by entering configuration information
into Configuration and Output tags created in RSLogix 5000 software for
the 1769-HSC module.
3. Monitor the Current Count value from the 1769-HSC module in the
Input Tag created for the module.
4. Verify that module outputs 0 and 1 turn on when the Current Counts
value is within the specified ranges.
845F Encoder Wire Color 1769-HSC Terminal
Blue/black wire pair Blue A0+
Black A0-
White/black wire pair White B0+
Black B0-
Green/black wire pair Green Z0+
Black Z0-
Red/black wire pair Red 24V DC power supply
Black 24V DC common
