142 Rockwell Automation Publication 1769-UM006E-EN-P - July 2013
Appendix C Program a 1769-HSC Module, MicroLogix 1500 Controller, and 845F Incremental Encoder with RSLogix 500 Software
845F Encoder Wiring to the
1769-HSC Module
Scope
These steps are used in this example.
1. Add the 1769-HSC module into a MicroLogix 1500 system by using
RSLogix 500 software.
2. Configure the 1769-HSC module by entering configuration information
into I/O Configuration created in RSLogix 500 software for the
1769-HSC module.
3. Monitor the Current Count value from the 1769-HSC module.
4. Verify that module outputs 0 and 1 turn on when the Current Count value
is within the specified ranges.
845F Encoder Wire Color 1769-HSC Terminal
Blue/Black Wire Pair Blue A0+
Black A0-
White/Black Wire Pair White B0+
Black B0-
Green/Black Wire Pair Green Z0+
Black Z0-
Red/Black Wire Pair Red 24V DC Power Supply
Black 24V DC Common
