150 Rockwell Automation Publication 1769-UM006E-EN-P - July 2013
Appendix D Programming Quick Reference
38
39
Ctr3MinCount
(4)
Ctr3MinCount
40
41
Ctr3Preset Ctr3Preset
42 Ctr3Hysteresis Ctr3Hysteresis
43 Ctr3Scalar
(5)
Ctr3Scalar
44 Ctr3CyclicRateUpdateTime
(6)
Ctr3CyclicRateUpdateTime
45
Linear Ctr3ConfigFlags ® Ctr3Config.Linear
46
47
Range0to11[0].HighLimit Range0to11[0].HighLimit
48
49
Range0to11[0].LowLimit Range0to11[0].LowLimit
50 Out15 Out14 Out13 Out12 Out11 Out10 Out09 Out08 Out07 Out06 Out05 Out04 Out03 Out02 Out01 Out00 Range0to11[0].OutputControl
51
Inv Type ToThisCtr Range0to11[0].ConfigFlags ® Range0To11[0].ToThisCounter_0
Range0To11[0].ToThisCounter_1
Range0To11[0].Type
Range0To11[0].Invert
52
53
Range0to11[1].HighLimit Range0to11[1].HighLimit
54
55
Range0to11[1].LowLimit Range0to11[1].LowLimit
56 Out15 Out14 Out13 Out12 Out11 Out10 Out09 Out08 Out07 Out06 Out05 Out04 Out03 Out02 Out01 Out00 Range0to11[1].OutputControl
57
Inv Type ToThisCtr Range0to11[1].ConfigFlags ® Range0To11[1].ToThisCounter_0
Range0To11[1].ToThisCounter_1
Range0To11[1].Type
Range0To11[1].Invert
58
59
Range0to11[2].HighLimit Range0to11[2].HighLimit
60
61
Range0to11[2].LowLimit Range0to11[2].LowLimit
62 Out15 Out14 Out13 Out12 Out11 Out10 Out09 Out08 Out07 Out06 Out05 Out04 Out03 Out02 Out01 Out00 Range0to11[2].OutputControl
63
Inv Type ToThisCtr Range0to11[2].ConfigFlags ® Range0To11[2].ToThisCounter_0
Range0To11[2].ToThisCounter_1
Range0To11[2].Type
Range0To11[2].Invert
64
65
Range0to11[3].HighLimit Range0to11[3].HighLimit
66
67
Range0to11[3].LowLimit Range0to11[3].LowLimit
68 Out15 Out14 Out13 Out12 Out11 Out10 Out09 Out08 Out07 Out06 Out05 Out04 Out03 Out02 Out01 Out00 Range0to11[3].OutputControl
69
Inv Type ToThisCtr Range0to11[3].ConfigFlags ® Range0To11[3].ToThisCounter_0
Range0To11[3].ToThisCounter_1
Range0To11[3].Type
Range0To11[3].Invert
70
71
Range0to11[4].HighLimit Range0to11[4].HighLimit
72
73
Range0to11[4].LowLimit Range0to11[4].LowLimit
74 Out15 Out14 Out13 Out12 Out11 Out10 Out09 Out08 Out07 Out06 Out05 Out04 Out03 Out02 Out01 Out00 Range0to11[4].OutputControl
75
Inv Type ToThisCtr Range0to11[4].ConfigFlags ® Range0To11[4].ToThisCounter_0
Range0To11[4].ToThisCounter_1
Range0To11[4].Type
Range0To11[4].Invert
76
77
Range0to11[5].HighLimit Range0to11[5].HighLimit
78
79
Range0to11[5].LowLimit Range0to11[5].LowLimit
80 Out15 Out14 Out13 Out12 Out11 Out10 Out09 Out08 Out07 Out06 Out05 Out04 Out03 Out02 Out01 Out00 Range0to11[5].OutputControl
81
Inv Type ToThisCtr Range0to11[5].ConfigFlags ® Range0To11[5].ToThisCounter_0
Range0To11[5].ToThisCounter_1
Range0To11[5].Type
Range0To11[5].Invert
82
83
Range0to11[6].HighLimit Range0to11[6].HighLimit
84
85
Range0to11[6].LowLimit Range0to11[6].LowLimit
86 Out15 Out14 Out13 Out12 Out11 Out10 Out09 Out08 Out07 Out06 Out05 Out04 Out03 Out02 Out01 Out00 Range0to11[6].OutputControl
87
Inv Type ToThisCtr Range0to11[6].ConfigFlags ® Range0To11[6].ToThisCounter_0
Range0To11[6].ToThisCounter_1
Range0To11[6].Type
Range0To11[6].Invert
88
89
Range0to11[7].HighLimit Range0to11[7].HighLimit
90
91
Range0to11[7].LowLimit Range0to11[7].LowLimit
92 Out15 Out14 Out13 Out12 Out11 Out10 Out09 Out08 Out07 Out06 Out05 Out04 Out03 Out02 Out01 Out00 Range0to11[7].OutputControl
93
Inv Type ToThisCtr Range0to11[7].ConfigFlags ® Range0To11[7].ToThisCounter_0
Range0To11[7].ToThisCounter_1
Range0To11[7].Type
Range0To11[7].Invert
94
95
Range0to11[8].HighLimit Range0to11[8].HighLimit
96
97
Range0to11[8].LowLimit Range0to11[8].LowLimit
98 Out15 Out14 Out13 Out12 Out11 Out10 Out09 Out08 Out07 Out06 Out05 Out04 Out03 Out02 Out01 Out00 Range0to11[8].OutputControl
99
Inv Type ToThisCtr Range0to11[8].ConfigFlags ® Range0To11[8].ToThisCounter_0
Range0To11[8].ToThisCounter_1
Range0To11[8].Type
Range0To11[8].Invert
100
101
Range0to11[9].HighLimit Range0to11[9].HighLimit
102
103
Range0to11[9].LowLimit Range0to11[9].LowLimit
104 Out15 Out14 Out13 Out12 Out11 Out10 Out09 Out08 Out07 Out06 Out05 Out04 Out03 Out02 Out01 Out00 Range0to11[9].OutputControl
Table 30 - Configuration Array for the 1769-HSC Module
1514131211109876543210Description
