Rockwell Automation Publication 1769-UM006E-EN-P - July 2013 153
Programming Quick Reference Appendix D
The default value for the output array is all zeroes.
Table 32 - Output Array for the 1769-HSC Module
1514131211109876543210 Description
0 Out15 Out14 Out13 Out12 Out11 Out10 Out09 Out08 Out07 Out06 Out05 Out04 Out03 Out02 Out01 Out00 OutputOnMask.0 -- OutputOnMask.15
1 Out15 Out14 Out13 Out12 Out11 Out10 Out09 Out08 Out07 Out06 Out05 Out04 Out03 Out02 Out01 Out00 OutputOffMask.0 -- OutputOffMask.15
2 R15 R14 R13 R12 R11 R10 R09 R08 R07 R06 R05 R04 R03 R02 R01 R00 RangeEn.0 -- RangeEn.15
3
Reserved
4
RBF ResetBlownFuse
5
RPW RREZ Z Inh Z Inv D Inh D Inv RCU RCO SP En Ctr0ControlBits Ctr0En
Ctr0SoftPreset
Ctr0ResetCountOverflow
Ctr0ResetCountUnderflow
Ctr0DirectionInvert
Ctr0DirectionInhibit
Ctr0ZInvert
Ctr0ZInhibit
Ctr0ResetRisingEdgeZ
Ctr0ResetCtrPresetWarning
6
RPW RREZ Z Inh Z Inv D Inh D Inv RCU RCO SP En Ctr1ControlBits
7
RPW D Inv RCU RCO SP En Ctr2ControlBits
8
RPW D Inv RCU RCO SP En Ctr3ControlBits
9
Reserved
10
11
Range12To15[0].HiLimOrDirWr Range12To15[0].HiLimOrDirWr
12
13
Range12To15[0].LowLimit Range12To15[0].LowLimit
14 Out15 Out14 Out13 Out12 Out11 Out10 Out09 Out08 Out07 Out06 Out05 Out04 Out03 Out02 Out01 Out00 Range12To15[0].OutputControl.0 ... .15
15
Inv LDW Type ToThisCtr Range12To15[0].Config Flags Range12To15[0].ToThisCounter_0
Range12To15[0].ToThisCounter_1
Range12To15[0].Type
Range12To15[0].LoadDirectWrite
Range12To15[0].Invert
16
17
Range12To15[1].HiLimOrDirWr Range12To15[1].HiLimOrDirWr
18
19
Range12To15[1].LowLimit Range12To15[1].LowLimit
20 Out15 Out14 Out13 Out12 Out11 Out10 Out09 Out08 Out07 Out06 Out05 Out04 Out03 Out02 Out01 Out00 Range12To15[1].OutputControl.0 ... .15
21
Inv LDW Type ToThisCtr Range12To15[1].Config Flags Range12To15[1].ToThisCounter_0
Range12To15[1].ToThisCounter_1
Range12To15[1].Type
Range12To15[1].LoadDirectWrite
Range12To15[1].Invert
22
23
Range12To15[2].HiLimOrDirWr Range12To15[2].HiLimOrDirWr
24
25
Range12To15[2].LowLimit Range12To15[2].LowLimit
26 Out15 Out14 Out13 Out12 Out11 Out10 Out09 Out08 Out07 Out06 Out05 Out04 Out03 Out02 Out01 Out00 Range12To15[2].OutputControl.0 ... .15
27
Inv LDW Type ToThisCtr Range12To15[2].Config Flags Range12To15[2].ToThisCounter_0
Range12To15[2].ToThisCounter_1
Range12To15[2].Type
Range12To15[2].LoadDirectWrite
Range12To15[2].Invert
28
29
Range12To15[3].HiLimOrDirWr Range12To15[3].HiLimOrDirWr
30
31
Range12To15[3].LowLimit Range12To15[3].LowLimit
32 Out15 Out14 Out13 Out12 Out11 Out10 Out09 Out08 Out07 Out06 Out05 Out04 Out03 Out02 Out01 Out00 Range12To15[3].OutputControl.0 ... .15
33
Inv LDW Type ToThisCtr Range12To15[3].Config Flags Range12To15[3].ToThisCounter_0
Range12To15[3].ToThisCounter_1
Range12To15[3].Type
Range12To15[3].LoadDirectWrite
Range12To15[3].Invert
