78 Rockwell Automation Publication 1769-UM006E-EN-P - July 2013
Chapter 4 Module Configuration, Output, and Input Data
Output Fault Value (Out0FaultValue through Out3FaultValue)
These bits are the values that will be applied to each of the real outputs when
User-defined Safe State is set as described and the module is in Fault state.
Counter Maximum Count (CtrnMaxCount)
This is the maximum count value allowed for counter (n). The count value
cannot exceed this value. Allowable values are CtrnMinCount 1…2,147,483,647
(decimal).
The default value is 2,147,483,647 decimal for counters 0 and 1. The default
value is 0 for counters 2 and 3.
Configuration Array Word 5 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
5 Output Fault Value
Not used Out3
FV
Out2
FV
Out1
FV
Out0
FV
TIP
Outputs are also affected by PFT above.
Configuration Array Words 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
6 Counter 0 Maximum
Count
Ctr0MaxCount
7
16 Counter 1 Maximum
Count
Ctr1MaxCount
17
26 Counter 2 Maximum
Count
Ctr2MaxCount
27
36 Counter 3 Maximum
Count
Ctr3MaxCount
37
IMPORTANT
Do not change this value while the counter is enabled. Attempting to do
so will result in a BadModConfigUpdate error. See page 120 for a list
of prohibited settings.
