Chapter 4 Module Configuration, Output, and Input Data
These 16-bit words indicate which outputs should be enabled when a range is
active. When range n is enabled, this word is combined with the other range
output masks as described in
Output Off Mask (OutputOffMask.0 through
OutputOffMask.15) on page 91 and on page 89.
Range Configuration Flags
ToThisCtr (Range0To11[n].ToThisCounter)
This 2-bit value indicates which counter is used in the range comparison for
range n, as shown in the table.
IMPORTANT
The Range Configuration Flag information does not apply to the L23E
packaged controller.
Configuration Array Words 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
51 Range 0 Configuration Flags
Not used Inv Not used Typ
e
Not used ToThisCtr
57 Range 1 Configuration Flags
Not used Inv Not used Typ
e
Not used ToThisCtr
63 Range 2 Configuration Flags
Not used Inv Not used Typ
e
Not used ToThisCtr
69 Range 3 Configuration Flags
Not used Inv Not used Typ
e
Not used ToThisCtr
75 Range 4 Configuration Flags
Not used Inv Not used Typ
e
Not used ToThisCtr
81 Range 5 Configuration Flags
Not used Inv Not used Typ
e
Not used ToThisCtr
87 Range 6 Configuration Flags
Not used Inv Not used Typ
e
Not used ToThisCtr
93 Range 7 Configuration Flags
Not used Inv Not used Typ
e
Not used ToThisCtr
99 Range 8 Configuration Flags
Not used Inv Not used Typ
e
Not used ToThisCtr
105 Range 9 Configuration Flags
Not used Inv Not used Typ
e
Not used ToThisCtr
111 Range 10 Configuration Flags
Not used Inv Not used Typ
e
Not used ToThisCtr
117 Range 11 Configuration Flags
Not used Inv Not used Typ
e
Not used ToThisCtr
Bit 01 Bit 00 Counter
000
011
102
113
