Chapter 4 Module Configuration, Output, and Input Data
Range Output Control (Range12To15[n].OutputControl)
This 16-bit word indicates which outputs should be on (corresponding bit set in
this word) when a range is active. When Rangen is enabled and active,
Range12To15[n].OutputControl will be logically OR’ed with other
Range12To15[n].OutputControl masks and the OutputOnMask.n and so forth.,
as described on
page 89.
When Range12To15[n].LoadDirectWrite is set,
Range12To15[n].OutputControl is ignored.
Range Configuration Flags (12To15)
IMPORTANT
For the L23E packaged controllers embedded HSC, the ranges referred to
in this section are numbered 0…3 instead of 12…15. The ranges in this
section apply to only the 1769-HSC module and the CMX 5370 L2
packaged controllers embedded HSC.
Output Array Words 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
14 Range 12 Output Control Range12To15[0].OutputControl
20 Range 13 Output Control Range12To15[1].OutputControl
26 Range 14 Output Control Range12To15[2].OutputControl
32 Range 15 Output Control Range12To15[3].OutputControl
IMPORTANT
For the L23E packaged controllers embedded HSC, the ranges referred to
in this section are numbered 0…3 instead of 12…15. The ranges in this
section apply to only the 1769-HSC module and the CMX 5370 L2
packaged controllers embedded HSC.
Output Array Words 15 14 13 12 11 10 09 08 07 06 05 04
(1)
03 02 01 00
15 Range 12 Configuration Flags
Not used Inv Not used LDW Type Not used ToThisCtr
21 Range 13 Configuration Flags
Not used Inv Not used LDW Type Not used ToThisCtr
27 Range 14 Configuration Flags
Not used Inv Not used LDW Type Not used ToThisCtr
33 Range 15 Configuration Flags
Not used Inv Not used LDW Type Not used ToThisCtr
(1) Bit 04 is not used for the packaged controller.
