Rockwell Automation Publication 1769-UM006E-EN-P - July 2013 99
Module Configuration, Output, and Input Data Chapter 4
8 Ctr[0].CurrentRate Counter 0 Current
Rate
9
10 Ctr[0].PulseInterval Counter 0 Pulse
Interval
11
12
Not used C0PW RV Not used ID
W
REZ CUdf COvf Counter 0 Status
Flags
13
Not used Not used
14 Ctr[1].CurrentCount Counter 1 Current
Count
15
16 Ctr[1].StoredCount Counter 1 Stored
Count
17
18 Ctr[1].CurrentRate Counter 1 Current
Rate
19
20 Ctr[1].PulseInterval Counter 1 Pulse
Interval
21
22
Not used C1PW RV IC ID
W
REZ CUdf COvf Counter 1 Status
Flags
23
Not used Not used
24 Ctr[2].CurrentCount Counter 2 Current
Count
25
26 Ctr[2].CurrentRate Counter 2 Current
Rate
27
28
Not used C2PW RV IC ID
W
Not
use
d
CUdf COvf Counter 2 Status
Flags
29
Not used Not used
30 Ctr[3].CurrentCount Counter 3 Current
Count
31
32 Ctr[3].CurrentRate Counter 3 Current
Rate
33
34
Not used C3PW RV IC ID
W
Not
use
d
CUdf COvf Counter 3 Status
Flags
Table 16 - Input Array - 1769-HSC Module and CMX 5370 L2 Packaged Controller Embedded HSC (Continued)
Word Bit Function
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
