Publication 1771-IN036C-EN-P - July 2002

DC (10-30V) Output Module

Cat. No. 1771–OVN Series B

This document provides information on:

See page

Important User Information 1

Preinstallation Considerations 4

Calculate Power Requirements 4

Initial Handling 5

Key the I/O Chassis 5

Install the Module and Field Wiring Arm 6

Connect Wiring to the Field Wiring Arm 7

Replacing the Fuse 10

For this reference information See page

Intepreting the Status Indicators 10

Hazardous Location Approval 11

Specifications 12

Because of the variety of uses for the products described in this

publication, those responsible for the application and use of these

products must satisfy themselves that all necessary steps have been

taken to assure that each application and use meets all performance

and safety requirements, including any applicable laws, regulations,

codes and standards. In no event will Rockwell Automation be

responsible or liable for indirect or consequential damage resulting

from the use or application of these products.

Any illustrations, charts, sample programs, and layout examples

shown in this publication are intended solely for purposes of

example. Since there are many variables and requirements associated

with any particular installation, Rockwell Automation does not

assume responsibility or liability (to include intellectual property

liability) for actual use based upon the examples shown in this

publication.

Important User Information

Installation Instructions

To The Installer

Summary of content (16 pages)

PAGE 1
Installation Instructions DC (10-30V) Output Module Cat. No.
PAGE 2
DC (10–30V) Output Module Allen–Bradley publication SGI–1.1, Safety Guidelines for Application, Installation, and Maintenance of Solid–State Control (available from your local Rockwell Automation office), describes some important differences between solid–state equipment and electromechanical devices that should be taken into consideration when applying products such as those described in this publication.
PAGE 3
DC (10–30V) Output Module ATTENTION ! 3 Environment and Enclosure This equipment is intended for use in a Pollution Degree 2 industrial environment, in overvoltage Category II applications (as defined in IEC publication 60664–1), at altitudes up to 2000 meters without derating. This equipment is considered Group 1, Class A industrial equipment according to IEC/CISPR Publication 11.
PAGE 4
DC (10–30V) Output Module ATTENTION ! Preventing Electrostatic Discharge This equipment is sensitive to electrostatic discharge, which can cause internal damage and affect normal operation. Follow these guidelines when you handle this equipment: • Touch a grounded object to discharge potential • • • • • PreĆinstallation Considerations static. Wear an approved grounding wriststrap. Do not touch connectors or pins on component boards. Do not touch circuit components inside the equipment.
PAGE 5
DC (10–30V) Output Module Initial Handling Procedures ATTENTION ! Keying the I/O Chassis ATTENTION ! Place your module in any slot in the chassis except the leftmost slot, which is reserved for processors or adapters. ATTENTION ! Remove power from the 1771 I/O chassis backplane and field wiring arm before removing or installing an I/O module. • Failure to remove power from the backplane or wiring arm could cause module damage, degradation of performance, or injury.
PAGE 6
DC (10–30V) Output Module Install the Module and Field Wiring Arm ATTENTION ! Remove power from the 1771 I/O chassis backplane and field wiring arm before removing or installing an I/O module. • Failure to remove power from the backplane or wiring arm could cause module damage, degradation of performance, or injury. • Failure to remove power from the backplane could cause injury or equipment damage due to possible unexpected operation.
PAGE 7
DC (10–30V) Output Module Connect Wiring to the Module WARNING ! ATTENTION ! 7 When you connect or disconnect the wiring arm with field power applied, an electrical arc can occur. This could cause an explosion in hazardous location installations. Be sure power is removed or the area is nonhazardous before proceeding. Remove power from the 1771 I/O chassis backplane and field wiring arm before removing or installing an I/O module.
PAGE 8
DC (10–30V) Output Module Connection Diagram for the 1771ĆOVN/B DC Output Module Note: Terminals on the left are even numbered (2 thru 40) , and terminals on the right are odd numbered (1 thru 39). Terminals 1 through 20 represent module group 1. Terminals 21 through 40 represent module group 2. Terminals 10, 20, 30 and 40 are dc common and terminals 1, 11, 21, and 31 are dc power.
PAGE 9
DC (10–30V) Output Module Table B Module Output Terminal Assignments Terminal Number Output Assignment I/O program address Terminal Number Output Assignment I/O program address 01 1 10 to 30V dc Ć 21 1 10 to 30V dc Ć 02 Output 00 0RG00 22 Output 00 0RG00 03 Output 01 0RG01 23 Output 01 0RG01 04 Output 02 0RG02 24 Output 02 0RG02 05 Output 03 0RG03 25 Output 03 0RG03 06 Output 04 0RG04 26 Output 04 0RG04 07 Output 05 0RG05 27 Output 05 0RG05 08 Output 06
PAGE 10
DC (10–30V) Output Module Interpreting the Status Indicators The module has 32 status indicators on the module front plate. These represent the control status of the outputs. Each indicator is lit when its corresponding output is energized. An additional indicator is provided to indicate a blown fuse condition.
PAGE 11
DC (10–30V) Output Module 11 The following information applies when operating this equipment in hazardous locations: Products marked CL I, DIV 2, GP A, B, C, D" are suitable for use in Class I Division 2 Groups A, B, C, and D Hazardous Locations and nonhazardous locations only. Each product is supplied with markings on the rating nameplate indicating the hazardous location temperature code.
PAGE 12
DC (10–30V) Output Module Specifications Outputs per module 32 (4 groups of 8) Module Location 1771ĆA1B thru ĆA4B or later I/O Chassis Voltage Rating 10 to 30V dc, 0.5A per output, 2A per group, 8A per module Maximum Output Current Rating Maximum Output Current Rating 0.5A per output (not to exceed 8A per module) 2A per output group Maximum Surge Current 2A per output for 10ms; repeatable every 2 seconds. 5A per output group for 10ms; repeatable every 2 seconds.
PAGE 13
DC (10–30V) Output Module Specifications (cont.) 13 Emissions CISPR 11 Group 1, Class A (with appropriate enclosure) Enclosure Type Rating None (open-style) Keying Between 14 and 16 Between 32 and 34 Fuse Four 4.0A, 250V normal blow fuses (1 per group); SAN-O Corporation ST4-4.0A Field Wiring Arm Catalog Number 1771ĆWN Wiring Arm Screw Torque 9 pound-inches (1.
PAGE 14
DC (10–30V) Output Module Publication 1771-IN036C-EN-P - July 2002
PAGE 15
DC (10–30V) Output Module 15 Publication 1771-IN036C-EN-P - July 2002
PAGE 16
DC (10–30V) Output Module Publication 1771-IN036C-EN-P - July 2002 Supersedes publication 1771Ć5.36 - February 2000 Publication 1771-IN036C-EN-P - July 2002 PN957678-78 Copyright 2002 Rockwell Automation, Inc.
