ArmorBlock 4 Output Module
Publication 1792-5.4 – October 1996
Mounting Dimensions
6.24
2.63
2.5
7.74
1.90
3.055
4 mounting holes
for #10 screws
(77.6)
(48.3)
(158.5)
(66.7)
(63.5)
(196.6)
(184.2)
7
.
25
Inches
(Millimeters)
Block dimensions allow T -port tap
connection directly onto connector
For washdown installations,
or excessively moist areas,
mount block with micro
connectors down.
MOD/NET
STATUS
NODE
ADDRESS
DATA
RA
TE
ARMORBLOCK I/O
1792-OB4E
Direction of liquid flow
