Par Parameter Name Factory Default Programmed Value Par Parameter Name Factory Default Programmed Value
104 Preset Speed 4 30.0 Hz 195 MOP Rate 1.0 Hz/s
105 Preset Speed 5 40.0 Hz 196 Param Access Lvl Basic
106 Preset Speed 6 50.0 Hz 197 Reset To Defalts Ready
107 Preset Speed 7 60.0 Hz 198 Load Frm Usr Set Ready
117 Trim In Select Analog In 2 199 Save To User Set Ready
118 Trim Out Select 0 200 Reset Meters Ready
119 Trim Hi 60.0 Hz 201 Language Not Selected
120 Trim Lo 0.0 Hz 202 Voltage Class Based on Drive Cat. No.
121 Slip RPM @ FLA Based on [Motor NP RPM] 203 Drive Checksum Read Only
122 Slip Comp Gain 40.0 209 Drive Status 1 0
123 Slip RPM Meter Read Only 210 Drive Status 2 0
124 PI Configuration 0 211 Drive Alarm 1 0
125 PI Control 0 212 Drive Alarm 2 0
126 PI Reference Sel PI Setpoint 213 Speed Ref Source Read Only
127 PI Setpoint 50.00% 214 Start Inhibits 1
128 PI Feedback Sel Analog In 2 215 Last Stop Source Read Only
129 PI Integral Time 2.00 Secs 216 Dig In Status 0
130 PI Prop Gain 1.00 217 Dig Out Status 0
131 PI Lower Limit -[Maximum Freq] 218 Drive Temp Read Only
132 PI Upper Limit +[Maximum Freq] 219 Drive OL Count Read Only
133 PI Preload 0.0 Hz 220 Motor OL Count Read Only
134 PI Status 0 224 Fault Frequency Read Only
135 PI Ref Meter Read Only 225 Fault Amps Read Only
136 PI Fdback Meter Read Only 226 Fault Bus Volts Read Only
137 PI Error Meter Read Only 227 Status 1 @ Fault 0
138 PI Output Meter Read Only 228 Status 2 @ Fault 0
140 Accel Time 1 10.0 Secs 229 Alarm 1 @ Fault 0
141 Accel Time 2 10.0 Secs 230 Alarm 2 @ Fault 0
142 Decel Time 1 10.0 Secs 234 Testpoint 1 Sel 499
143 Decel Time 2 10.0 Secs 235 Testpoint 1 Data Read Only
146 S-Curve % 0% 236 Testpoint 2 Sel 499
147 Current Lmt Sel Cur Lim Val 237 Testpoint 2 Data Read Only
148 Current Lmt Val [Rated Amps] x 1.5 238 Fault Config 1 0
149 Current Lmt Gain 250 240 Fault Clear Ready
150 Drive OL Mode Both-PWM 1st 241 Fault Clear Mode Enabled
151 PWM Frequency 4 kHz 242 Power Up Marker Read Only
155 Stop Mode A Ramp 243 Fault 1 Code Read Only
156 Stop Mode B Coast 244 Fault 1 Time Read Only
157 DC Brk Lvl Sel DC Brake Lvl 245 Fault 2 Code Read Only
158 DC Brake Level [Rated Amps] 246 Fault 2 Time Read Only
159 DC Brake Time 0.0 sec 247 Fault 3 Code Read Only
160 Bus Reg Ki 450 248 Fault 3 Time Read Only
161 Bus Reg Mode A Adjust Freq 249 Fault 4 Code Read Only
162 Bus Reg Mode B Both-Frq 1st 250 Fault 4 Time Read Only
163 DB Resistor Type Internal Res 251 Fault 5 Code Read Only
164 Bus Reg Kp 500 252 Fault 5 Time Read Only
165 Bus Reg Kd 1000 253 Fault 6 Code Read Only
168 Start At PowerUp Disabled 254 Fault 6 Time Read Only
169 Flying Start En Disabled 255 Fault 7 Code Read Only
170 Flying StartGain 4000 256 Fault 7 Time Read Only
174 Auto Rstrt Tries 0 257 Fault 8 Code Read Only
175 Auto Rstrt Delay 1.0 Secs 258 Fault 8 Time Read Only
178 Sleep-Wake Mode Disabled 259 Alarm Config 1 1
179 Sleep-Wake Ref Analog In 2 261 Alarm Clear Ready
180 Wake Level 6.000 mA, 6.000 Volts 262 Alarm 1 Code Read Only
181 Wake Time 1.0 Secs 263 Alarm 2 Code Read Only
182 Sleep Level 5.000 mA, 5.000 Volts 264 Alarm 3 Code Read Only
183 Sleep Time 1.0 Secs 265 Alarm 4 Code Read Only
184 Power Loss Mode Coast 266 Alarm 5 Code Read Only
185 Power Loss Time 0.5 Secs 267 Alarm 6 Code Read Only
186 Power Loss Level Drive Rated Volts 268 Alarm 7 Code Read Only
190 Direction Mode Unipolar 269 Alarm 8 Code Read Only
192 Save HIM Ref 1 270 DPI Baud Rate 125 kbps
193 Man Ref Preload Disabled 271 Drive Logic Rslt 0
194 Save MOP Ref 0 272 Drive Ref Rslt Read Only
