PowerFlex 700 Parameter Record
Machine #
Date programmed
Drive Serial #
Par Parameter Name Minimum Value Maximum Value Factory Default Programmed Value
128 PI Feedback Sel PI Setpoint Analog In 2
Analog In 1
Analog In 2
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
MOP Level
Master Ref
Preset Spd1
Preset Spd2
Preset Spd3
Preset Spd4
Preset Spd5
Preset Spd6
Preset Spd7
DIP Port 1
DPI Port 2
DPI Port 3
DPI Port 4
DPI Port 5
129 PI Integral Time 0.00 Secs 100.00 Secs 2.00 Secs
130 PI Prop Gain 0.00 100.00 1.00
131 PI Lower Limit
-400.0 Hz
+400.0 Hz
-[Maximum Freq]
132 PI Upper Limit
-400.0 Hz
+400.0 Hz
+[Maximum Freq]
133 PI Preload
-400.0 Hz
+400.0 Hz
0.0 Hz
134 PI Status PI Enabled 0
PI Hold 0
PI Reset 0
PI InLimit 0
135 PI Ref Meter -100.00 % +100.00 % Read Only
136 PI Fdback Meter -100.00 % +100.00 % Read Only
137 PI Error Meter -100.00 % +100.00 % Read Only
138 PI Output Meter -[Maximum Freq] +[Maximum Freq] Read Only
140 Accel Time 1 0.1 Secs 3600.0 Secs 10.0 Secs
141 Accel Time 2 0.1 Secs 3600.0 Secs 10.0 Secs
142 Decel Time 1 0.1 Secs 3600.0 Secs 10.0 Secs
143 Decel Time 2 0.1 Secs 3600.0 Secs 10.0 Secs
146 S-Curve % 0% 100% 0%
147 Current Lmt Sel Cur Lim Val Cur Lim Val
Analog In 1
Analog In 2
148 Current Lmt Val
Based On Drive Rating
Based On Drive Rating
[Rated Amps] x 1.5
149 Current Lmt Gain 0 5000 250
150 Drive OL Mode Disabled Both-PWM 1st
Reduce CLim
Reduce PWM
Both-PWM 1st
151 PWM Frequency
2 kHz
10 kHz
4 kHz
155 Stop Mode A Coast Ramp
Ramp
Ramp to Hold
DC Brake
4 of 17
