122 Rockwell Automation Publication 20D-PM001C-EN-P - July 2013
Chapter 2 Programming and Parameters
No. Name
Description
Values
Linkable
Read-Write
Data Type
1028 Swtch DInt 1 Out
This is the result of the switch. The output is loaded with the selected input based on Par 1022 [Sel Switch Ctrl],
bit 6 “SW DInt 1 On”. If this parameter does not update, check the setting of Par 1000 [UserFunct Enable], bit 1
“User Params”.
Default:
Min/Max:
0.0000
-/+2200000000.0000
RO 32-bit
Integer
1029
to
1044
Sel Swtch In00
to
Sel Swtch In15
Set these values for the inputs to the selector switch specified in Par 1022 [Sel Switch Ctrl]. All inputs are entered
as Real values. You may use the output of the selector switch as either Real or DInt. A conversion is done to create
the DInt value.
Default:
Min/Max:
0.0000
-/+2200000000.0000
Y
RW Real
1045 SelSwtch RealOut
This is the result of the selector switch. The output is loaded with the selected input based on Par 1022 [Sel
Switch Ctrl], bit 0 and bits 1-4. The output is only updated when Par 1022 [Sel Switch Ctrl], bit 0 “SSW DataPass”
is high. If Par 1022 [Sel Switch Ctrl], bit 0 is not high the output will not be updated to the selected input. If this
parameter does not update, check the setting of Par 1000
[UserFunct Enable], bit 1 “User Params”.
Default:
Min/Max:
0.0000
-/+2200000000.0000
RO Real
1046 SelSwtch DIntOut
This value is the value of Par 1045 [SelSwtch RealOut] converted to a DInt value. Use this value for point to point
positioning values.
Default:
Min/Max:
0
-/+2147483648
RO 32-bit
Integer
1047 DInt2Real1 In
Input value for a first DInt to Real value conversion.
Note: This parameter name changed from [DInt2Real In] to [DInt2Real1 In] for firmware version 3.001.
Default:
Min/Max:
0
-/+2147483648
Y
RW 32-bit
Integer
1048 DInt2Real1 Scale
Input value to scale the first conversion from DInt to Real. This is a multiplication to the input value after
conversion to a Real value.
Note: This parameter name changed from [DInt2Real Scale] to [DInt2Real1 Scale] for firmware version 3.001.
Default:
Min/Max:
0.0000
-/+2200000000.0000
Y
RW Real
1049 DInt2Real1Result
This is the resultant output of the first conversion form a DInt value to a Real value after scaling.
Note: This parameter name changed from [DInt2RealResult] to [DInt2Real1Result] for firmware version 3.001.
Default:
Min/Max:
0.0000
-/+2200000000.0000
RO Real
1050 Real2DInt In
Input value for Real to DInt value conversion.
Default:
Min/Max:
0.0000
-/+2200000000.0000
Y
RW Real
1051 Real2DInt Scale
Input value to scale the conversion from Real to DInt. This is a multiplication to the input value after conversion to
a DInt value.
Default:
Min/Max:
0.0000
-/+2200000000.0000
Y
RW Real
1052 Real2DInt Result
This is the resultant output of the conversion form a Real value to a DInt value after scaling.
Default:
Min/Max:
0
-/+2147483648
RO 32-bit
Integer
1053 MulDiv 1 Input
Input value to be scaled as need with the Multiplication and Division function. This input will be multiplied by Par
1054 [MulDiv 1 Mul] and then divided by Par 1055 [MulDiv 1 Div]. The result will be loaded to Par 1056 [MulDiv 1
Result].
Equation: (Par 1053
x Par 1054) / Par 1055 = Par 1056
Default:
Min/Max:
0.0000
-/+2200000000.0000
Y
RW Real
1054 MulDiv 1 Mul
Set this value as the multiplier to the value of Par 1053 [MulDiv 1 Input]. The result will be divided by Par 1055
and loaded into Par 1056
. See Par 1053.
Default:
Min/Max:
0.0000
-/+2200000000.0000
Y
RW Real
1055 MulDiv 1 Div
Set this value as the divisor of the result of Par 1053 x Par 1054. The result will be loaded into Par 1056. See Par
1053.
Default:
Min/Max:
0.0000
-/+2200000000.0000
Y
RW Real
1056 MulDiv 1 Result
This is the result output from the Multiplication and Division function. See Par 1053.
Equation: Par 1056
= (Par 1053 x Par 1054) / Par 1055
Default:
Min/Max:
0.0000
-/+2200000000.0000
RO Real
1057 MulDiv 2 Input
Input value to be scaled as need with the Multiplication and Division function. This input will be multiplied by Par
1058 [MulDiv 2 Mul] and then divided by Par 1059 [MulDiv 2 Div]. The result will be loaded to Par 1060 [MulDiv 2
Result].
Equation: (Par 1057
x Par 1058) / Par 1059 = Par 1060
Default:
Min/Max:
0.0000
-/+2200000000.0000
Y
RW Real
1058 MulDiv 2 Mul
Set this value as the multiplier to the value of Par 1057 [MulDiv 2 Input]. The result will be divided by Par 1059
and loaded into Par 1060
. See Par 1057.
Default:
Min/Max:
0.0000
-/+2200000000.0000
Y
RW Real
1059 MulDiv 2 Div
Set this value as the divisor of the result of Par 1057 x Par 1058. The result will be loaded into Par 1060. See Par
1057.
Default:
Min/Max:
0.0000
-/+2200000000.0000
Y
RW Real
1060 MulDiv 2 Result
This is the result output from the Multiplication and Division function. See Par 1057.
Equation: Par 1060
= (Par 1057 x Par 1058) / Par 1059
Default:
Min/Max:
0.0000
-/+2200000000.0000
RO Real
