Chapter 3 Troubleshooting
43 VoltageFdbk Loss 2 A loss of motor or DC Bus voltage feedback has occurred because of a
communication failure between Motor Control and Voltage Feedback board.
• Check the communication line between Motor
Control (MC) and the Voltage Feedback board.
• Replace the Voltage Feedback board.
Configured with Par 394
[VoltFdbkLossCnfg].
44 Runtime Data Rst 3 Runtime data (hours, energy) has been reset to zero due to a checksum error. (Informational Only)
45 Enable Health 1 The safety circuit is active. Check the input signal to the safety circuit.
46 Interp Out Synch 2 The interpolator for position feedback lost synchronization with the Velocity
Position Loop (VPL).
Configured with Par 378
[Interp Flt Cnfg].
47 MC CML Task Fail 3 The Current Minor Loop (CML) task has been delayed or run with an incorrect
interval.
Cycle power to the drive.
48 No Ctrl Device 1 The controlling device (HIM or controller) has been disconnected while the
drive was running.
Check the controlling device connections to the drive.
49 DPI Loss Port 1 2 The device at DPI port 1 has stopped communicating with the drive.
A SCANport device is connected to a drive operating DPI devices at 500k Baud.
Verify that the DPI device is present and functional at
port 1.
Configured with Par 391
[DPI CommLoss Cfg].
50 DPI Loss Port 2 2 The device at DPI port 2 has stopped communicating with the drive.
A SCANport device is connected to a drive operating DPI devices at 500k Baud.
Verify that the DPI device is present and functional at
port 2.
Configured with Par 391 [DPI CommLoss Cfg].
51 DPI Loss Port 3 2 The device at DPI port 3 has stopped communicating with the drive.
A SCANport device is connected to a drive operating DPI devices at 500k Baud.
Verify that the DPI device is present and functional at
port 3.
Configured with Par 391
[DPI CommLoss Cfg].
52 DPI Loss Port 4 2 The device at DPI port 4 has stopped communicating with the drive.
A SCANport device is connected to a drive operating DPI devices at 500k Baud.
Verify that the DPI device is present and functional at
port 4.
Configured with Par 391
[DPI CommLoss Cfg].
53 DPI Loss Port 5 2 The device at DPI port 5 has stopped communicating with the drive.
A SCANport device is connected to a drive operating DPI devices at 500k Baud.
Verify that the DPI device is present and functional at
port 5.
Configured with Par 391 [DPI CommLoss Cfg].
54 DPI Loss Port 6 2 The device at DPI port 6 has stopped communicating with the drive.
A SCANport device is connected to a drive operating DPI devices at 500k Baud.
Verify that the DPI device is present and functional at
port 6.
Configured with Par 391
[DPI CommLoss Cfg].
55 Net Loss DPI P1 2 A communications fault has occurred between the communication adapter at
DPI port 1 and the network.
Verify the network connection.
Verify the status of network.
Configured with Par 392 [NetLoss DPI Cnfg].
56 Net Loss DPI P2 2 A communications fault has occurred between the communication adapter at
DPI port 2 and the network.
Verify the network connection.
Verify the status of network.
Configured with Par 392
[NetLoss DPI Cnfg].
57 Net Loss DPI P3 2 A communications fault has occurred between the communication adapter at
DPI port 3 and the network.
Verify the network connection.
Verify the status of network.
Configured with Par 392
[NetLoss DPI Cnfg].
58 Net Loss DPI P4 2 A communications fault has occurred between the communication adapter at
DPI port 4 and the network.
Verify the network connection.
Verify the status of network.
Configured with Par 392 [NetLoss DPI Cnfg].
59 Net Loss DPI P5 2 A communications fault has occurred between the communication adapter at
DPI port 5 and the network.
Verify the network connection.
Verify the status of network.
Configured with Par 392
[NetLoss DPI Cnfg].
60 Net Loss DPI P6 2 A communications fault has occurred between the communication adapter at
DPI port 6 and the network.
Verify the network connection.
Verify the status of network.
Configured with Par 392
[NetLoss DPI Cnfg].
61 Logix Out of Run 2 The DriveLogix controller is in a Non-Run mode. Non-Run modes include
program, remote-program and faulted modes.
Clear the fault.
Configured with Par 386
[Lgx OutOfRunCnfg].
62 Logix Timeout 2 The communication connection to the DriveLogix controller has timed out. Configured with Par 387 [Lgx Timeout Cnfg].
63 Logix Closed 2 The DriveLogix controller has closed the Controller to Drive connection. Verify that the Drive is present in the Controller I/O
configuration.
Configured with Par 388
[Lgx Clod Cnfg].
64 Logix Link Chng 2 A required link in the Controller to Drive Communication Format has been
modified.
Clear the fault.
Configured with Par 389
[Lgx LinkChngCnfg].
65 HiHp In PhaseLs 2 (High Horse Power Only)
AC Input Phase Loss - the AC input phase voltage has fallen.
• Check for voltage on each AC input phase.
• Check the status of each external AC input fuse.
Configured with Par 370
[HiHp InPhsLs Cfg].
