204 Rockwell Automation Publication 20D-PM001C-EN-P - July 2013
Appendix D PowerFlex 700S Permanent Magnet Motor Specifications
1326AH-B330F 460 2.1 0.0 3000 0.75 - 9.0 - 3000
1326AH-B440F 460 3.3 0.0 2500 1.22 - 13.8 - 2500
1326AH-B540F 460 11.1 0.0 2500 2.60 - 47.2 - 2500
3050R-7 390 66.0 50.0 500 30.00 12 132.0 - 500
11050R-7 390 218.0 50.0 500 110.00 12 436.0 - 500
(1) Due to low inertia and low electrical time constant characteristics, it is recommended that the system inertia be at least 0.02 seconds when using this motor for constant velocity applications.
Parameter No. 1 2 3 4 5 7
Model Number Motor NP Volts
(line to line V rms)
Motor NP FLA
(A rms)
Motor NP
Frequency
(Hz)
Motor NP RPM
(oper. rpm)
Motor NP
Power (KW)
Motor
Poles
Current peak
(A rms)
System Cont. Stall
Torque (N•m)
Motor Max
RPM
(rpm)
