Chapter 2 Programming and Parameters
321 Exception Event2
Indicates the presence of certain drive anomalies. Configure the drive's response to these events by entering values in the parameters of the fault/alarm configuration group of the utility file.
Note: Changed bit 14 to “NonCnfgAlarm” for firmware version 3.003.
322 Exception Event3
Indicates the presence of certain drive anomalies. Configure the drive's response to these events by entering values in the parameters of the fault/alarm configuration group of the utility file.
• Bit 11 “HH HW Ver” is sed to indicate a High Horsepower hardware version fault.
• Bit 12 “HH CurUnblnc” is used to indicate a High Horsepower output current unbalanced fault.
• Bit 13 “HH VltUnblnc” is used to indicate a High Horsepower Bus voltage unbalanced fault.
• Bit 29 “AnlgIn1 Loss” is used to indicate an Analog Input 1 loss fault.
• Bit 30 “AnlgIn2 Loss” is used to indicate an Analog Input 2 loss fault.
• Bit 31 “AnlgIn3 Loss” is used to indicate an Analog Input 3 loss fault.
Notes: Bits 16, 20 and 23 were added for firmware version 2.004. Bits 11, 12, 13, 29, 30 and 31 were added for firmware version 3.001. Changed bits 11, 12, 13, 21, and 28 to “NonCnfgAlarm” for
firmware version 3.003. Bit 14 “NonCnfgAlarm” was added for firmware version 3.004.
323 Fault Status 1
Indicates the occurrence of exception events that have been configured as fault conditions. These events are from Par 320 [Exception Event1].
324 Fault Status 2
Indicates the occurrence of exception events that have been configured as fault conditions. These events are from Par 321 [Exception Event2]
Note: Changed bit 14 to “NonCnfgAlarm” for firmware version 3.003.
325 Fault Status 3
Indicates the occurrence of exception events that have been configured as fault conditions. These events are from Par 322 [Exception Event3].
• Bit 11 “HH HW Ver” is sed to indicate a High Horsepower hardware version fault.
• Bit 12 “HH CurUnblnc” is used to indicate a High Horsepower output current unbalanced fault.
• Bit 13 “HH VltUnblnc” is used to indicate a High Horsepower Bus voltage unbalanced fault.
• Bit 29 “AnlgIn1 Loss” is used to indicate an Analog Input 1 loss fault.
• Bit 30 “AnlgIn2 Loss” is used to indicate an Analog Input 2 loss fault.
• Bit 31 “AnlgIn3 Loss” is used to indicate an Analog Input 3 loss fault.
Notes: Bits 16, 20 and 23 were added for firmware version 2.004. Bits 11, 12, 13, 29, 30 and 31 were added for firmware version 3.001. Changed bit 21 to “Drive Homing” and bit 28 to “+/- 12v Pwr”
for firmware version 3.003. Bit 14 “NonCnfgAlarm” was added for firmware version 3.004.
No. Name
Description
Values
Linkable Read-Write Data Type
Options
Lgx LinkChng Lgx Closed Lgx Timeout Lgx OutOfRun NetLoss DPI6 NetLoss DPI5 NetLoss DPI4 NetLoss DPI3 NetLoss DPI2 NetLoss DPI1 DPI Loss P6 DPI Loss P5 DPI Loss P4 DPI Loss P3 DPI Loss P2 DPI Loss P1 No Ctrl Devc NonCnfgAlarm Interp Synch EnableHealth NonCnfgAlarm VoltFdbkLoss BusUnderVolt RidethruTime Slink Mult PowerEE Cksm BrakeOL Trip PSC Sys Flt2 PSC Sys Flt1 Ctrl EE Cksm MC Command +/- 12v Pwr
Default 00000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
Options
AnlgIn3 Loss AnlgIn2 Loss AnlgIn1 Loss NonCnfgAlarm Reserved Reserved Reserved Reserved NonCnfgAlarm Reserved NonCnfgAlarm Posit Err -Hrd OvrTrvl +Hrd OvrTrvl -Sft OvrTrvl +Sft OvrTrvl Reserved NonCnfgAlarm NonCnfgAlarm NonCnfgAlarm NonCnfgAlarm HH PwrBdTemp HH PwrEE Er HHPrChrgCntc HH PwrBd Prc HH Drv Ovrld HH FanFdbkLs HH BusWtchDg HH BusCRC Er HH BusLinkLs HH BusComDly HH InPhaseLs
Default 0000xxxx0x000000x000000000000000
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
Options
PWM Asynchro Precharge Er MC Firmware PWM Short VPL/MC Comm OverCurrent Ground Fault Trans Desat Bus OverVolt MC Commissn Over Freq Inertia Test DSP Error DSP Mem Err Ext Fault In Inv OL Trip Inv OL Pend Inv OTmpTrip Inv OTmpPend Motor Stall Mtr OL Pend Mtr OL Trip Power Loss SLink Comm SLink HW Ctrl EE Mem FB Opt1 Loss FB Opt0 Loss Encdr1 Loss Encdr0 Loss SpdRef Decel Abs OverSpd
Default 00000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
Options
Lgx LinkChng Lgx Closed Lgx Timeout Lgx OutOfRun NetLoss DPI6 NetLoss DPI5 NetLoss DPI4 NetLoss DPI3 NetLoss DPI2 NetLoss DPI1 DPI Loss P6 DPI Loss P5 DPI Loss P4 DPI Loss P3 DPI Loss P2 DPI Loss P1 No Ctrl Devc NonCnfgAlarm Interp Synch EnableHealth NonCnfgAlarm VoltFdbkLoss BusUnderVolt RidethruTime Slink Mult PowerEE Cksm BrakeOL Trip PSC Sys Flt2 PSC Sys Flt1 Ctrl EE Cksm MC Command +/- 12v Pwr
Default 00000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
Options
AnlgIn3 Loss AnlgIn2 Loss AnlgIn1 Loss NonCnfgAlarm Reserved Reserved Reserved Reserved NonCnfgAlarm Reserved NonCnfgAlarm Posit Err -Hrd OvrTrvl +Hrd OvrTrvl -Sft OvrTrvl +Sft OvrTrvl Reserved NonCnfgAlarm NonCnfgAlarm NonCnfgAlarm NonCnfgAlarm HH PwrBdTemp HH PwrEE Er HHPrChrgCntc HH PwrBd Prc HH Drv Ovrld HH FanFdbkLs HH BusWtchDg HH BusCRC Er HH BusLinkLs HH BusComDly HH InPhaseLs
Default 0000xxxx0x000000x000000000000000
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
