Programming and Parameters Chapter 2
555 MC Status
Indicates the status of the Motor Control (MC) Processor and related functions.
Note: Changed bit 18 from “Reserved” to “Vqs Reg Act” for firmware version 3.003.
556 Trend Control
Set bits to configure the Data Trend function:
• Bit 0 “Enbl Collect” - Trend data collection begins on the rising edge of this bit and continues until either this bit is set low or the trend data has been completely collected. This bit should be
cleared following either the 'Triggered' status or 'Complete' status in order to complete the trend sequence. This bit can also be cleared at any time to force the trend data sampling to stop and
set the 'Complete' status bit.
• Setting bit 1 “In1 Real” - specifies the Real data type for Trend Input 1. The source for Real data is Par 571
[Trend In1 Real]. Clearing the bit specifies the Integer data type. The source for Integer
data is Par 570
[Trend In1 DInt].
• Setting bit 2 “In2 Real” - specifies the Real data type for Trend Input 2. The source for Real data is Par 575
[Trend In2 Real]. Clearing the bit specifies the Integer data type. The source for Integer
data is Par 574
[Trend In2 DInt].
• Setting bit 3 “In3 Real” - specifies the Real data type for Trend Input 3. The source for Real data is Par 579 [Trend In3 Real]. Clearing the bit specifies the Integer data type. The source for Integer
data is Par 578 [Trend In3 DInt].
• Setting bit 4 “In4 Real” - specifies the Real data type for Trend Input 4. The source for Real data is Par 583
[Trend In4 Real]. Clearing the bit specifies the Integer data type. The source for Integer
data is Par 582 [Trend In4 DInt].
• Setting bit 15 “Auto Output” causes the trend output parameters to automatically cycle through the entire trend buffer at the rate specified in Par 559 [Trend Rate]. Typically, you link the output
to an analog output for display on an oscilloscope.
• Auto output is accomplished by writing to Par 569
[TrendBuffPointer]. Clearing this bit requires manual selection of Par 569 [TrendBuffPointer] to view the trend buffer contents.
557 Trend Status
Bits indicate the status of the Data Trend function:
• Bit 1 “Triggered” indicates a Trend Trigger event has been detected. This bit will clear in response to the rise of Par 556 [Trend Control], bit 0 “Enbl Collect”.
• Bit 2 “Complete” indicates all the post trigger data samples have been gathered and the trend buffers are full. It will also be set if the Par 556 [Trend Control], bit 0 “Enbl Collect” is cleared before
the trigger occurs. The trend data outputs will be updated from the contents of the trend buffer data when this bit is set. Par 556 [Trend Control], bit 0 “Enbl Collect” can be cleared after this bit
is set without affecting the trend data buffer contents. This bit will clear in response to the rise of Par 556 [Trend Control], bit 0 “Enbl Collect”. The trend outputs will be forced to zero while this bit
is clear.
No. Name
Description
Values
Linkable Read-Write Data Type
Options
Min Vqs MaxDCBus Vqs MaxMotor Vqs Max Vds Min Vds SrLssWsLimit Slip Limit Regen Iqs Limit FldWeakening MC FW Group2 Reserved Reserved Vqs Reg Act FluxRatioRef Command Lim DC Bus Low MC Test Mode PreChrg Req PWM En PreChrg Done Flux En Torque En Change Dir MC CommisFlt MC CommisRun MC Fault MC Ready BaseBlockReq Tor qu eRu nR eq Flux Run Req MC En Req
Default 00000000000xx0000000000000000000
Bit 313029282726252423222120191817161514131211109876543210
0 = False
1 = True
Options
Auto Output Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved In 4 Real In 3 Real In 2 Real In 1 Real Enbl Collect
Default 0xxxxxxxxxx00000
Bit 1514131211109876543210
0 = False
1 = True
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Complete Triggered Reserved
Default xxxxxxxxxxxxxxxxxxxxxxxxxxxxx00x
Bit 313029282726252423222120191817161514131211109 8 7 6 5 4 3 2 1 0
0 = False
1 = True
