4-50 Application Guide
• Variable Array Size. The size of the array (16 to 128 characters
for RIO) containing the variable data. The maximum array size is
dependent on the controller and must be an even integer.
The address tags are an Integer (N) data file. Both the Message Trigger
and Message Data addresses must fall entirely within its designated
block transfer, including the Message Data array size.
Block Transfer Parameters
• Address. The starting address (in the correct controller format)
of the message data for the Block Transfer Read or Block
Transfer Write.
• Length. The number of words to transfer (1 to 62, or 64). The
InView display uses Length to identify the message blocks. You
must configure 2 block transfers (only 2). The first block, labeled
Message, contains both the Message Trigger and Data addresses.
The second block, labeled Variable, contains the Variable Trigger
and Variable Data addresses. Word 63 is reserved for the RIO
Pass-through.
Save or Download an
Application File
After you select a communication protocol and configure the
communication and tag parameters, or if you opened a previously
saved .ivc configuration file, download or save the application file.
The last screen that displays lets you download or save the
configuration.
Configuration Download or Save
IMPORTANT
Variable Trigger and Variable Data addresses work
the same as Variable Array Size.
