1 Publication 2706-UM017C-EN-P - March 2006
Appendix
A
InView Communication Module
Specifications
Communication
Specifications
Power Supply
Requirements
The 2706-P_M and 2706-P_K modules are powered by the InView
2706-P4x, 2706-P7x and 2706-P9x displays.
The 2706-P_P module requires an external 24V ±25 percent, 1 A DC
power supply for use with the InView 2706-P22R panel mount
display.
Attribute Value
Operating Temperature (Inside Panel) 0…55 °C (32…131 °F)
Storage Temperature -25…70 °C (-13…158 °F)
Humidity (Operating and Non-Condensing) 5 … 95%
Shock 15 g Maximum Pulse Operating
30 g Maximum Pulse Non-Operating
Vibration - Channel Mount 10 Hz < f < 57 Hz 0.012 in. p-p displacement
57 Hz < f 500 Hz 1.0g
Vibration - DIN Rail Mount 10 Hz < f < 57 Hz 0.012 in. p-p displacement
57 Hz < f 500 Hz 2.0g
