Publication 2706-UM017C-EN-P - March 2006
Introduction to InView Connectivity 1-9
8. If creating a new InView network communications file, select a
protocol from the list. Then, choose an InView serial
communication rate.
This is the communication rate that the communication module
and the InView display communicate at.
Currently all InView displays communicate at 9600 bps, with the
exception of the 2706-P92 and 2706-P94 displays. Those can
communicate at either 9600 bps or 19200 bps.
9. Setup the communication and tag setup screens dependent
upon the protocol and type of controller.
How to setup the communication and tag setup screens is
described in Chapter 4.
