Publication 2706-UM017C-EN-P - March 2006
3-2 InView Communication Module Connections
Cable Tables
Refer to the following tables for a summary of InView communication
module connections to controllers and network interface modules.
Runtime Communication Cables - To Processors
InView to SLC
Protocol InView Standard Comm Port SLC-500, 5/01,
5/02
CH1 RJ45
(DH-485)
SLC-5/03, 5/04, 5/05
CH0 (9-pin RS-232)
(DF1 or DH-485)
SLC 5/03
CH1 (RJ45)
(DH-485)
SLC 5/04
CH1
(DH+)
SLC 5/05
CH1
(ENET)
DH-485 DH-485 Communication Port (RJ45) 1747-C10
(2m/6ft)
1747-C11
(0.3m/1ft)
1747-C20
(6m/20ft)
use AIC+ Module
(1761-NET-AIC)
Connect to Port 3
1747-C10
(2m/6ft)
1747-C11
(0.3m/1ft)
1747-C20
(6m/20ft)
N/A N/A
DeviceNet DeviceNet Communication Port to SLC 5/02
with 1747-SDN
and
DeviceNet cable
use 1747-SDN Module with DeviceNet cable
ControlNet ControlNet Communication Port N/A not applicable - InView communication module does not support
SLC ControlNet configurations
EtherNet/IP Ethernet Comm Port N/A N/A N/A N/A Ethernet
cable
InView to PLC-5, ControlLogix, MicroLogix1000, MicroLogix 1200, and MicroLogix 1500LSP
Protocol InView Communication Module
Standard Comm Port
PLC-5, PLC-5C, PLC-5E
CH0 (25-pin RS-232)
(DF1)
ControlLogix
CH0 (9-pin RS-232)
(DF1)
MicroLogix 1000, 1200,
1500LSP
CH0 (8-pin Mini DIN)
(DF1 or DH-485)
DH-485 DH-485 Communication Port (RJ45) N/A N/A use AIC+ Module
(1761-NET-AIC)
Connect to Port 3
DeviceNet DeviceNet Communication Port use 1771-SDN Module
with
DeviceNet cable
use 1756-DNB Module
with
DeviceNet cable
use 1761-NET-DNI
Module with DeviceNet
cable
ControlNet ControlNet Communication Port to PLC-5C
with
ControlNet cable
use 1756-CNB Module
with
ControlNet cable
N/A
