Publication 2706-UM017C-EN-P - March 2006
InView Communication Module Connections 3-3
EtherNet/IP Ethernet Communication Port to PLC-5E with
Ethernet cable
Use 1756-ENET Module
with Ethernet cable
Use 1761-NET-ENI
Module with Ethernet
cable
Remote I/O Remote I/O Communication Port shielded twinaxial cable
(1770-CD)
use 1756-DHRIO Module
with shielded twinaxial
cable (1770-CD)
N/A
DH+ DH+ Communication Port shielded twinaxial cable
(1770-CD)
use 1756-DHRIO Module
with shielded twinaxial
cable
(1770-CD)
N/A
InView to PLC-5, ControlLogix, MicroLogix1000, MicroLogix 1200, and MicroLogix 1500LSP
Protocol InView Communication Module
Standard Comm Port
PLC-5, PLC-5C, PLC-5E
CH0 (25-pin RS-232)
(DF1)
ControlLogix
CH0 (9-pin RS-232)
(DF1)
MicroLogix 1000, 1200,
1500LSP
CH0 (8-pin Mini DIN)
(DF1 or DH-485)
InView to MicroLogix 1500LRP, CompactLogix, and FlexLogix
Protocol InView Communication Module
Standard Comm Port
MicroLogix 1500LRP
CH1 (9-pin RS-232)
(DF1 or DH-485)
CompactLogix CH0
(9-pin RS-232)
(DF1 or DH-485)
FlexLogix
CH0 (9-pin RS-232)
(DF1)
DH-485 DH-485 Communication Port (RJ45) use AIC+ Module
(1761-NET-AIC)
Connect to Port 3
use AIC+ Module
(1761-NET-AIC)
Connect to Port 3
N/A
DeviceNet DeviceNet Communication Port use 1761-NET-DNI Module
with DeviceNet cable
N/A
ControlNet ControlNet Communication Port N/A N/A use 1788-CNC module
with ControlNet cable
EtherNet/IP Ethernet Communication Port use 1761-NET-ENI
Module with Ethernet
cable
use 1761-NET-ENI
Module with Ethernet
cable
use 1761-NET-ENI Module
with Ethernet cable
Remote I/O Remote I/O Communication Port N/A N/A N/A
DH+ DH+ Communication Port N/A N/A N/A
