3-4 InView Communication Module Connections
Runtime Communication Cables - to Network Interface Module
Application File Download (Direct) Cables
Remote I/O Connections
This section describes connections for the remote I/O InView
communication modules including:
• remote I/O port.
• supported controllers.
• making remote I/O connections.
• remote I/O Pass-through.
InView to 1747-AIC, 1761-NET-AIC, 1761-NET-DNI, and 1761-NET-ENI
Protocol InView Communication
Module Standard Comm
Port
1747-AIC 1761-NET-AIC 1761-NET-DNI or
1761-NET-ENI
DH-485 DH-485 Communication Port
(RJ45)
1747-C10
(2m/6ft)
1747-C11
(0.3m/1 ft)
1747-C20
(6m/20ft)
N/A N/A 1761-CBL-AS03
(3m/10ft)
1761-CBL-AS09
(9m/30ft)
N/A
Download Cables
InView Communication Module Standard Type Cable to Personal Computer
DH-485 Comm Port only or DH-485 Comm Port and RS-232 Port 1747-PIC
DeviceNet Comm Port and RS-232 Port 2711-NC13 (5 m/16 ft)
2711-NC14 (10 m/32 ft)
2706-NC13 (3 m/10 ft)
ControlNet Comm Port and RS-232 Port
Remote I/O Comm Port and RS-232 Port
Ethernet Comm Port and RS-232 Port
DH+ Comm Port and RS-232 Port
