3-6 InView Communication Module Connections
Supported RIO Connections
Controller Scanner Comments
ControlLogix 1756-DHRIO Connect InView communication modules through the 1756-DHRIO
module.
PLC-5/11, 5/15
(1)
,
5/20, 5/25,
5/30, 5/60, 5/80,
5/250
PLC Integral 1771-SN Connect InView communication modules directly to the remote I/O
port (scanner mode). Connect InView communication modules
through the 1771-SN subscanner module.
PLC-5/10, 5/12 1771-SN Connect InView communication modules through the 1771-SN
subscanner module.
PLC-2
1771-SN or 1772-SD2
(2)
Connect InView communication modules to the PLC-2 family of
processors through a 1771-SN I/O subscanner module.
PLC-3 and
PLC-3/10
None
PLC-3/10
Remote I/O Scanner
(3)
Connect InView communication modules directly to a PLC-3.
Connect InView communication modules to the PLC-3/10 through the
remote I/O scanner.
SLC 5/02, 5/03, 5/04,
5/05
1747-SN Connect InView communication modules through the 1747-SN
subscanner module. Each module provides an additional remote I/O
link for up to 4 racks.
(4)
IBM PC 6008-SI 6008-SI I/O scanner is compatible with IBM PC or compatible
computers. The scanner provides a computer access to the 1771
remote I/O link.
VME 6008-SV 6008-SV I/O scanner provides access to the 1771 remote I/O link for
VME controllers.
DEC Q-BUS 6008-SQ 6008-SQ I/O scanner provides access to the 1771 remote I/O link for
DEC Q-BUS controllers.
(1)
If using a PLC-5/15 with partial rack addressing and block transfers, you must use Series B, Rev. J or later.
(2)
If using a 1772-SD2 Remote Scanner/Distribution Panel, use revision 3 or later.
(3)
If using a 1775-S4A Remote Scanner/Distribution Panel, use Series B or later.
(4)
Only Series B and later versions of the 1747-SN subscanner support block transfers.
