Publication 2706-UM017C-EN-P - March 2006
InView Communication Module Connections 3-27
Computer Connection
Computer
To RS-232 Port of
9-pin female
9-pin male
1
2
3
4
5
6
7
8
9
TXD (Data Transmit)
RXD (Data Receive)
COM
DTR
DSR
RTS
CTS
NC
DCD
InView Communication Module
1
2
3
4
5
6
7
8
9
NC
NC
RTS
CTS
NC
NC
Printer/Computer Port (DTE)
1
4
5
6
7
8
9
NC
NC
NC
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
Available Cables Cat. No.
2711-NC13, 5 m (16.4 ft) Cat. No.
2711-NC14, 10 m (32.7 ft) Cat. No.
2706-NC13, 3 m (10 ft)
with Handshaking
TXD
RXD
RS-232 Port
COM
InView Communications Module
InView Communication Module
2706-P4x
2706-P7x
2706-P9x
2706-P22R
2711-NC13
2711-NC14
2706-NC13
77156-094
