1 Publication 2706-UM017C-EN-P - March 2006
Chapter
1
Introduction to InView Connectivity
InView message displays come standard with RS-232 and RS-485
communications for quick and easy integration. For applications
requiring industrial or commercial networks, InView communications
modules can be used to integrate your display into new and existing
networks.
InView Communication Option
Network Communication Module
2706-P22R 2706-P42R, -P42C,
-P43R, -P43C,
-P44R, -P44C
2706-P72CN2,
-P74CN2,
-P72CN1, -P74CN1
Remote I/O 2706-PRIOP 2706-PRIOM 2706-PRIOK
DH-485 2706-PDH485P 2706-PDH485M 2706-PDH485K
DH+ 2706-PDHPP 2706-PDHPM 2706-PDHPK
DeviceNet 2706-PDNETP 2706-PDNETM 2706-PDNETK
ControlNet 2706-PCNETP 2706-PCNETM 2706-PCNETK
EtherNet IP 2706-PENETP 2706-PENETM 2706-PENETK
Ethernet TCP/IP
(1)
(1)
Rockwell Automation recommends using a third party DIN rail mounted Ethernet TCP/IP solution with the
InView P22R panel mount display. Lantronixs and Digi both supply a DIN rail Ethernet TCP/IP solution for
connectivity to a personal computer.
2706-PENET1
