1 Publication 2727-UM002D-EN-P
Appendix
A
Specifications
General
Electrical
General
Processor Intel StrongARM SA-1110/206 mHz
Operating System
2727-G7P20D1P4, -G7P20D1P5
2727-G7P20D1Q6, -G7P20D3Q7
Microsoft Windows CE 3.0
Microsoft Windows CE 4.1
Memory
2727-G7P20D1P4, -G7P20D1P5
2727-G7P20D1Q6, -G7P20D3Q7
16M DRAM/32M Flash
64M DRAM/64M Flash
Display Passive LCD 7.7-inch VGA with 256 colors
Touch Screen 7.7-inch analog resistive
Keypad Stainless steel dome membrane switches
with tactile feedback
Housing Double-walled ABS housing, resistive to
grease, oil, lubricants, alcohol, silicone free
Flammability class: UL 94-V0
Dimensions
Diameter 290 mm (11.42 inches)
Depth without handle 80 mm (3.15 inches)
Depth with handle 130 mm (5.12 inches)
Weight 1550 grams (3.42 lbs) - without options
Electrical
Nominal Supply Voltage 24V dc safety-extra-low-voltage
Supply Voltage Range 18V dc to 32V dc
Typical Input Current 300mA at 24V dc
Peak Inrush Current 5.6A maximum
Power Supply 10 ms minimum holdup time
(EN 61131-2:1994 + A11:1996 + A12:2000
and EN 50178:1997)
