Terminal Connections 3-13
Making an Ethernet
Connection
The MobileView terminal is equipped with a 10Base-T interface which
supports TCP/IP protocol at 10MBaud for half-duplex
communications.
The Ethernet connector at S3 on the Junction Box provides a
connection to an Ethernet network. The connector uses an 8-pin
modular jack connector. Pinouts are as follows:
Using the PC Card Slot
The PC card slot is a factory installed option and supports Type I, II,
and III PC cards. The following PC cards are available from
Allen-Bradley. The terminal does not support SRAM cards, CardBus
cards, or cards that use 12 volts for programming.
Pin # Ethernet Signal
1TD+
2TD-
3RD+
4 Not Used
5 Not Used
6RD-
7 Not Used
8 Not Used
Catalog No. Description
2711-NM28 8M flash ATA card for storing applications.
2711-NM216 16M flash ATA card for storing applications.
2711-NM232 32M flash ATA card for storing applications.
