126 Rockwell Automation Publication 280E-UM001B-EN-P – July 2012
Chapter 7 Bulletin 280E/281E/284E Programmable Parameters
Anti-bounce OFF Delay
This parameter allows the installer to
program a time duration before an
input is reported “OFF” (Anti-bounce).
Parameter Number 31
Access Rule GET/SET
Data Type UINT
Group User I/O Config.
Units ms
Minimum Value 0
Maximum Value 65
Default Value 0
In Sink/Source
This parameter allows the installer to
program the inputs to be sink or
source.
0 = Sink
1 = Source
Parameter Number 32
Access Rule GET/SET
Data Type BOOL
Group User I/O Config.
Units —
Minimum Value 0
Maximum Value 1
Default Value 0
OutA Pr FltState
This parameter in conjunction with
Parameter 34 (OutA Pr FltValue)
defines how Output A will respond
when a protection trip occurs.
0 = Goto Pr FltValue
1 = Ignore Pr Flt
When set to “1”, Output A continues to
operate as command via the network.
When set to “0”, Output A will open or
close as determined by setting in
Parameter 34.
Parameter Number 33
Access Rule GET/SET
Data Type BOOL
Group User I/O Config.
Units —
Minimum Value 0
Maximum Value 1
Default Value 0
OutA Pr FltValue
This parameter determines the state
the Output A assumes when a trip
occurs and Parameter 33 (OutA Pr
FltState) is set to “0”.
0 = Open
1 = Close
Parameter Number 34
Access Rule GET/SET
Data Type BOOL
Group User I/O Config.
Units —
Minimum Value 0
Maximum Value 1
Default Value 0
