Rockwell Automation Publication 280E-UM001B-EN-P – July 2012 189
Bulletin 280E/281E/284E Programmable Parameters Chapter 7
A
Step if Logic In2 is Active and Logic In1 is Not Active
b
Step after (StpLogic Time x) and Logic In1 is Active
C
Step after (StpLogic Time x) and Logic In2 is Active
d
Step after (StpLogic Time x) and Logic In1 is Not Active
E
Step after (StpLogic Time x) and Logic In2 is Not Active
F
Do Not Stop/Ignore Digit 2 Settings
Table 26 - Digit 2 Settings
0
Jump to Step 0
1
Jump to Step 1
2
Jump to Step 2
3
Jump to Step 3
4
Jump to Step 4
5
Jump to Step 5
6
Jump to Step 6
7
Jump to Step 7
8
End Program (Normal Stop)
9
End Program (Coast to Stop)
A
End Program and Fault (F2)
Table 27 - Digit 3 Settings
Required
Setting
Accel/Decel Parameter
Used
StepLogic
Output State
Commanded Direction
0 Accel/Decel 1 OFF FWD
1 Accel/Decel 1 OFF REV
2 Accel/Decel 1 OFF No Output
3 Accel/Decel 1 ON FWD
4 Accel/Decel 1 ON REV
5 Accel/Decel 1 ON No Output
6 Accel/Decel 2 OFF FWD
7 Accel/Decel 2 OFF REV
8 Accel/Decel 2 OFF No Output
9 Accel/Decel 2 ON FWD
A Accel/Decel 2 ON REV
b Accel/Decel 2 ON No Output
Table 25 - Digit 0 and Digit 1 Settings
