Rockwell Automation Publication 280E-UM001B-EN-P – July 2012 193
Bulletin 280E/281E/284E Programmable Parameters Chapter 7
Linear List of Parameters
for Bulletin 280E/281E and
Bulletin 284E
Table 28 - ArmorStart Common Parameters
Parameter
Number Parameter Name Description Factory Default Group Controller
1 Hdw Inputs
This parameter provides status of hardware inputs.
0 Basic Status Common
2Network Inputs
This parameter provides status of network inputs.
0 Basic Status Common
3Network Outputs
This parameter provides status of network outputs.
0 Basic Status Common
4Trip Status
This parameter provides trip identification.
0 Basic Status Common
5Starter Status
This parameter provides the status of the starter.
0 Basic Status Common
6 InternalLinkStat
Status of the internal network connections.
0 Basic Status Common
7 Starter Command
The parameter provides the status of the starter
command.
0 Basic Status Common
8 Network Override
This parameter allows for the local logic to override a
Network fault.
0 Misc. Configuration Common
9 Comm Override
This parameter allows for local logic to override a
absence of an I/O connection.
0 Misc. Configuration Common
10 Reserved
— —
Network Configuration Common
11 Reserved
— —
Network Configuration Common
12 Reserved
— —
Network Configuration Common
13 Prod Assy Word 0
This parameter is used to build bytes 0…1 for
produced assembly 150 or 151.
0 Network Configuration Common
14 Prod Assy Word 1
This parameter is used to build bytes 2…3 for
produced assembly 150 or 151.
0 Network Configuration Common
15 Prod Assy Word 2
This parameter is used to build bytes 4…5 for
produced assembly 150 or 151.
0 Network Configuration Common
16 Prod Assy Word 3
This parameter is used to build bytes 6…7 for
produced assembly 150 or 151.
0 Network Configuration Common
17 Reserved
— —
Basic Status Common
18 Reserved
— —
Basic Status Common
19 Reserved
— —
Network Configuration Common
20 Reserved
— —
Network Configuration Common
21 Reserved
— —
Network Configuration Common
22 Breaker Type
This parameter identifies the Bulletin 140M used in this
product.
0 =
140M-D8N-C10
Basic Status Common
23 Pr FltReset Mode
This parameter configures the Protection Fault reset
mode.
0 = Manual Starter Protection Common
24 Pr Fault Enable
This parameter enables the Protection Fault by setting
the bit to 1.
12419 Starter Protection Common
25 Pr Fault Reset
This parameter resets the Protection Fault on a
transition 0 > 1.
0 Starter Protection Common
