Bulletin 280E/281E/284E Programmable Parameters Chapter 7
44 OutB Net IdlValue
This parameter determines the state that Output B
assumes when the network is idle and Parameter 43
(OutB Net IdlState) is set to “0”.
0 = Open User I/O Configuration Common
45 Keypad Mode
This parameter selects if the keypad operation is
maintained or momentary.
0 = Maintained Misc. Configuration Common
46 Keypad Disable
This parameter disables all keypad function except for
the OFF and RESET buttons.
0 = Not Disabled Misc. Configuration Common
47 Set To Defaults
This parameter if set to 1 will set the device to the
factory defaults.
0 = No Operation Misc. Configuration Common
48 Drive Control
This parameter provides the status of drive parameters.
0Drive I/O Configuration284E
49 DrvIn Pr FltState
This parameter, in conjunction with Parameter 50
(DrvIn Pr FltValue), defines how the Drive Digital Inputs
1…4 will respond when a protection trip occurs.
0 =
Go to PrFlt Value
Drive I/O Configuration 284E
50 DrvIn Pr FltValue
This parameter determines the state of Drive Digital
Inputs 1…4, assumes when a trip occurs.
0 = Open Drive I/O Configuration 284E
51 DrvIn Net FltState
This parameter, in conjunction with Parameter 52
(DrvIn Net FltValue), defines how the Drive Digital
Inputs 1…4 will respond when a network fault occurs.
0 =
Go to Fault Value
Drive I/O Configuration 284E
52 DrvIn Net FltValue
This parameter determines the state of Drive Digital
Inputs 1…4 when a network fault occurs and
Parameter 51 (DrvIn Net FltState) is set to “0”.
0 = OFF Drive I/O Configuration 284E
53 DrvIn Net FItState
This parameter, in conjunction with Parameter 54
(DrvIn Net FItValue), defines how the Drive Digital
Inputs 1…4 will respond when a DeviceNet™ network
is idle.
0 =
Go to Fault Value
Drive I/O Configuration 284E
54 DrvIn Net FItValue
This parameter determines the state that Drive Digital
Inputs 1…4 assume when the network is idle and
Parameter 53 (DrvIn Net FItState) is set to “0”.
0 = OFF Drive I/O Configuration 284E
55 High Speed Enaable
This parameter enable High Speed Inverter control thru
the terminal block.
0 = Disabled Drive I/O Configuration 284E
56 Base Enclosure
Indicates the ArmorStart Base unit enclosure rating.
1 Basic Status Common
57 Base Options
Indicates the options for the ArmorStart Base unit.
0 Basic Status Common
58 Wiring Options
This parameter provides the Wiring Options.
0 Basic Status Common
59 Starter Enclosure
This parameter provides the Starter Enclosure.
1 Basic Status Common
60 Starter Options
This parameter provides the Starter Options.
0 Basic Status Common
61 Last PR Fault
This parameter provides the Last PR Fault.
0 = None Basic Status Common
62 Warning Status
This parameter provides the Warning Status.
0 Basic Status Common
63 Base Trip
This parameter provides the Base Module Trip Status.
0 Basic Status Common
101 Phase A Current
This parameter provides the current of Phase A.
0Starter DisplayDOL
102 Phase B Current
This parameter provides the current of Phase B.
0Starter DisplayDOL
103 Phase C Current
This parameter provides the current of Phase C.
0Starter DisplayDOL
104 Average Current
This parameter provides the average current.
0Starter DisplayDOL
Table 28 - ArmorStart Common Parameters
Parameter
Number Parameter Name Description Factory Default Group Controller
