Rockwell Automation Publication 280E-UM001B-EN-P - July 2012 247
Specifications for EtherNet/IP Chapter 11
Bulletin 284E
Electrical Ratings UL/NEMA IEC
Power Circuit
Rated Operation Voltage 200…575V 200…500V
Rate Insulation Voltage 600V 600 V
Rated Impulsed Voltage 6 kV 6 kV
Dielectric Withstand 2200V AC 2500V AC
Operating Frequency 50/60 Hz 50/60 Hz
Utilization Category N/A AC-3
Protection Against Shock N/A IP2X
Control
Circuit
Rated Operation Voltage 24V DC (+10%, –15%) A2 (should be grounded at voltage source)
Rate Insulation Voltage 250V 250V
Rated Impulsed Voltage — 4 kV
Dielectric Withstand 1500V AC 2000V AC
Overvoltage Category — III
Operating Frequency 50/60 Hz 50/60 Hz
Short Circuit
Protection
SCPD Performance Type 1
Current Rating Voltage 480Y/277V 480Y/480V 600Y/347V 600V
10 A
Sym. Amps rms
65 kA 65 kA 30 kA 30 kA
25 A 30 kA 30 kA 30 kA 30 kA
SCPD List Size per NFPA 70 (NEC) or NFPA 79 for Group Motor Applications
UL/NEMA IEC
Environmental
Operating Temperature Range –20…40°C (–4…104°F)
Storage and Transportation
Temperature Range
–25….85°C (–13…185°F)
Altitude 1000 m
Humidity 5…95% (on-condensing)
Pollution Degree 3
Enclosure Ratings NEMA 4/12 IP67
Approximate Shipping Weight 13.6 kg (30 lb)
Mechanical
Resistance to Shock
Operational 15 G
Non-Operational 30 G
Resistance to Vibration
Operational 1 G, 0.15 mm (0.006 in.) Displacement
Non-Operational 2.5 G, 0.38 mm (0.015 in.) Displacement
Power and Ground Terminals
Wire Size
Primary/Secondary Terminal:
#16…#10 AWG
Primary/Secondary Terminal:
1.0…4.0 mm2
Tightening Torque
Primary Terminal: 10.8 lb·in.
Secondary Terminal: 4.5 lb·in.
Primary Terminal: 1.2 N·m
Secondary Terminal: 0.5 N·m
Wire Strip Length 0.35 in. (9 mm)
Control and Safety Monitor Inputs
WireSize #18…#10 AWG 1.0…4.0 mm2
Tightening Torque 6.2 lb·in. 0.7 N·m
Wire Strip Length 0.35 in. (9 mm)
Disconnect Lock Out
Maximum of 5/16 in. (8 mm) lock shackle or hasp. The hasp should not exceed
5/16 in. (8 mm) when closed, or damage will occur to disconnect guard.
