254 Rockwell Automation Publication 280E-UM001B-EN-P - July 2012
Chapter 12 Accessories
➊ Available in 0.3, 0.6, 1, 2, 5, 10, 15, and increments of 5 meters up to 75 meters.
Note: Refer to www.ab.com/networks/media/ethernet to learn more about
Industrial Ethernet Media.
Patchcords and Cordsets IP20 to IP67
Front Mount Receptacle Connector Type
Cat. No.
Unshielded
Female Front Mount
to
RJ45
1585D-D4TBJM- ➊
Transition Cable Connector Type Unshielded
Male Straight
to
RJ45
1585D-M4TBJM- ➊
M12 to RJ45 Bulkhead Adapter – 1585A Description Cat. No.
• Transition from IP20 environment to IP67 environment
• In-cabinet connectivity with RJ45 connector providing On-Machine solution with M12 D Code
connector
• Differential 100 ohm terminators used for unused pairs
• Cat 5e
1585A-DD4JD
