Rockwell Automation Publication 280E-UM001B-EN-P - July 2012 257
Accessories Chapter 12
Sealing Caps
➊ To achieve IP67 rating, sealing caps must be installed on all unused I/O connections.
Other
Description
EtherNet/IP
Input Output
Plastic Sealing Cap (M12) ➊ 1485A-M12 1485A-M12
Motor Connector Aluminum Sealing Cap
(M22) for 10A protection*
— 1485A-C1
Motor Connector Aluminum Sealing Cap
(M35) for 25A protection
— 889A-QMCAP
Dynamic Brake Connector (M22)
— 1485A-C1
Source/Control Brake Cap (M25) —
Contact Local Sales
Office
Description Cat. No.
Locking Tag
Padlock attachment to the lockable handles
Up to three padlocks 4…8 mm (5/16 in.) shackle
140M-C-M3
Replacement At-Motor Handle
Kit include (1) handle, (1) guard, and (3) screws
280-DISHDL
Replacement Fan for 284 Control Module
284-FAN
