288 Rockwell Automation Publication 280E-UM001B-EN-P – July 2012
Appendix B CIP Information
Discrete Input Point Object
CLASS CODE 0x0008
The following class attributes are currently supported for the Discrete Input
Point Object:
Four instances of the Discrete Input Point Object are supported. All instances
contain the following attributes.
The following common services will be implemented for the Discrete Input Point
Object.
Discrete Output Point Object
CLASS CODE 0x0009
The following class attributes are supported.
Four instances of the Discrete Output Point Object are supported for DOL/
Reverser units. Ten instances are supported for Drive units. The following table
summarizes the DOP instances.
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 2
2 Get Max Instance UINT 4
Attribute ID Access Rule Name Data Type Value
3 Get Value BOOL 0 = OFF, 1 = ON
115 Get/Set Force Enable BOOL 0 = Disable, 1 = Enable
116 Get/Set Force Value BOOL 0 = OFF, 1 = ON
Service Code
Implemented for:
Service NameClass Instance
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 1
2 Get Max Instance UINT 4 or 10
