Rockwell Automation Publication 280E-UM001B-EN-P – July 2012 297
CIP Information Appendix B
The following common services will be implemented for the DLR Object.
Qos Object
CLASS CODE 0x0048
The following class attributes will be supported for the QoS Object.
A single instance (Instance 1) will be supported and it contains the following
instance attributes.
The following common services will be implemented for the QoS Object.
DPI Fault Object
CLASS CODE 0x0097
The DPI Fault Object is implemented in the DeviceNet Main Control Board.
Service Code
Implemented for:
Service NameClass Instance
0x01 Yes Yes Get_Attribute_All
0x0E Yes Yes Set_Attribute_Single
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 1
Attribute ID Access Rule Name Data Type Value
1 Set 802 1Q Tag Enable USINT 0 = Disable (Default)
1 - Enable
4 Set DSCP Urgent USINT Default = 55
5 Set DSCP Scheduled USINT Default = 47
6 Set DSCP High USINT Default = 43
7 Set DSCP Low USINT Default = 31
8 Set DSCP Explicit USINT Default = 27
Service Code
Implemented for:
Service NameClass Instance
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
