Rockwell Automation Publication 280E-UM001B-EN-P – July 2012 345
Renewal Parts Appendix F
Base Module Renewal Part Product Selection
Figure 116 - Bulletin 284E Base Module Renewal Part Catalog Structure
Bulletin
Number
Communications
E EtherNet/IP
Enclosure Type
F Type 4 (IP67)
284 E – F N – 10 – C
Short-Circuit Protection
Bulletin 140 Current Rating (A)
10 10 A Rated Device
25 25 A Rated Device
Line Media
C Conduit
R ArmorConnect™ Power Media
Base
N Base Only — no starter
Table 63 - Bulletin 284E Base Module Renewal
Part, IP67/NEMA 4, With Conduit Entrance
Input Voltage kW Hp
24 V DC
Control Voltage
380…480V
50/60 Hz
3-Phase
0.4…2.2 0.5…3.0 280E-FN-10-C
3.0 5.0
280E-FN-25-C
380…480V
50/60 Hz
3-Phase
0.4…2.2 0.5…3.0
280E-FN-10-R
3.0 5.0
280E-FN-25-R
Table 64 - Dynamic Brake Cable
Description Cable Rating Length m (ft) Cat. No.
M22 Dynamic Brake Cable (DB Option) IP67/NEMA Type 4 3 (9.8) 285-DBK22-M3
