Manual

Manual/MDI Operation Modes
Chapter 4
4-14
Figure 4.6
MDI Mode Program Screen
PRGRAM
MANAGE
OFFSET MACRO
PARAM
PRGRAM
CHECK
SYSTEM
SUPORT
E-STOP
PROGRAM[ MM ] F 00000.000 MMPM
Z 00000.000 S 0
R X 00000.000 T 1
C 359.99
MEMORY 30000 MDI STOP N 99999
(First 4 blocks
of MDI shown here)
(PAL messages)
Important: Performing a block reset operation causes the control to abort
the current MDI program block or skip the following MDI program block.
See page 2-4 for details. By performing a control reset operation as
described, the control erases all MDI blocks that have not been executed in
the MDI program.
END OF CHAPTER
