Editing Programs On Line
Chapter 5
5-19
For more information regarding these designations, see chapters 15 and 16.
Your system installer can select a different address for angle A in AMP.
Refer to your system installer’s documentation.
Axis words followed by a (1), (2), or (3) are prompting for the first,
second, or third coordinate position respectively. The location of the axis
word is shown on the drawing accompanying the prompt screen.
Prompts that appear: Indicatethat:
in reverse video this parameter isoptional, and youdo not needto enter it
in this block.
with an OR tothe left there aretwo ormore optionalparameters forthis prompt,
only oneof which needsa valueassigned to it.
Follow these steps to use the QuickPath Plus QuickView feature:
1. From the QuickView menu, press the {QPATH+ PROMPT} softkey.
QPATH+
PROMPT
GCODE
PROMPT
DRILL
PROMPT
LATHE
PROMPT
PLANE
SELECT
(softkey level 4)
2. Select a sample pattern matching the part geometry to be
programmed from the previous list of sample patterns, and press the
corresponding softkey.
Change the softkey menu, by pressing the continue softkey {Þ}.
Figure 5.3
QuickPath Plus Menu Screen
