Editing Programs On Line
Chapter 5
5-22
Figure 5.5
G-code Prompt Select Screen
G CODE PROMPTING MENU DISPLAY PAGE 1 OF 3
G00/01 RAPID/LINEAR INTERPOLATION
G02/03 CIRCULAR/HELICAL INTERPOLATION, CW/CCW
G04 DWELL
G07/G08 RADIUS/DIAMETER PROGRAMMING
G09/61/62/ CUTTING MODE SELECTION
63/64
G10L2 WORK COORDINATE SYSTEM TABLE ENTRY
G10L0&11 TOOL LIFE MANAGEMENT TABLE ENTRY/CANCELLED
G10L10-L13 TOOL OFFSET TABLE ENTRY
G10.1L20 RANDOM TOOL DATA ENTRY
G14.1/14 SCALING ENABLED/DISABLED
G16/15 POLAR COORDINATE PROGRAMMING/CANCELLED
G16.1/15 CYLINDRICAL PROGRAMMING/CANCELLED
G16.2/15 VIRTUAL C AXIS PROGRAMMING/CANCELLED
SELECT
2. Position the cursor at the desired G-code to prompt by using the up
and down cursor keys. The selected G-code appears in reverse video.
3. Once you select the correct G-code, press the {SELECT} softkey. The
control displays screen with prompts for that G-code.
4. Use the up and down cursor keys to select the parameters to be
changed or entered. The selected item appears in reverse video.
Axis words followed by a (1), (2), or (3) are prompting for the first,
second, or third coordinate position respectively. The location of the
first, second, or third axis word is shown on the drawing
accompanying the prompt screen.
Prompts shown: Indicate that:
in reverse video this parameter isoptional and do not need to be entered inthis
block.
with an OR tothe left there aretwo or more optionalparameters for thisprompt, only
one of which needs avalue assigned.
5. Type in the desired data for that parameter on the input line of the
CRT, and press the [TRANSMIT] key.
