Editing Programs On Line
Chapter 5
5-48
When you press the {UPDATE & EXIT} softkey, the control does a
compile/check of the encryption/decryption table to determine that
no duplicate characters exist and that no characters were left blank.
If a characteris: the control displays: and moves thecursor:
entered twice “CHARACTERS CANONLY
BE ENTEREDONCE”
to the first occurrence of that character
in the encryption/decryption table
left blank “NO LOCATIONS CAN BE
LEFT EMPTY”
to the first blank locationin the
encryption/decryption table
Once the encryption/decryption table is created and you press the
{NCRYPT MODE} softkey, protected programs are encrypted when they are
uploaded to ODS or the Mini DNC package. When downloading
encrypted protected programs to the control, they are decrypted and loaded
into the protected program directory.
To prevent the encryption/decryption table from being lost during system
power failures and battery-backup failures, store it in the control’s backup
memory by using these steps:
1. Select the protected part program directory.
2. Press the {SET-UP NCRYPT} softkey.
REFORM
MEMORY
CHANGE
DIR
NCRYPT
MODE
SET-UP
NCRYPT
ACTIVE
PRGRAM
EDIT
PRGRAM
RESTRT
PRGRAM
DISPLY
PRGRAM
COPY
PRGRAM
VERIFY
PRGRAM
PRGRAM
COMENT
DELETE
PRGRAM
RENAME
PRGRAM
INPUT
DEVICE
(softkey level 2)
5.10.2
Storing Encryption/Decryption
Table to Backup Memory
