Manual

Manual/MDI Operation Modes
Chapter 1
1-5
HPG Hand Pulse Generator
I/O Input/Output
MDI Manual DataInput
Modal an operating condition that remains in effect on the control until cancelled
or replaced
MTB
Machine Tool Builder
ODS OfflineDevelopment System
PAL
Programmable Application Logic
RAM RandomAccess Memoryresident on the9/240
Softkeys the rowof keys directly belowthe screen
Super cap A super capacitor. Backs updata forup to 5 days on systemswithout
extended program storage. It recharges within1 hour of power turnon if
completely discharged.
System installer thecompany or contractor responsiblefor installing thiscontrol onthe
machine
TTRC Tool TipRadius Compensation
9/Series Documentation
Pub. No. Document Name
8520-4.3 9/SeriesCNC PAL ReferenceManual
8520--5.1.1 9/Series CNCLathe Operationand ProgrammingManual
8520--5.1.3 9/Series CNCMill Operationand ProgrammingManual
8520--5.1.4 9/Series CNCGrinder Operation and ProgrammingManual
8520-5.1.5 9/Series DataHighway PlusCommunication ModuleUser Manual
8520-5.1.6 9/Series MMS/Ethernet CommunicationModule UserManual
8520--5.2 9/Series CNCOCI User Manual Supplement
8520-6.2 9/SeriesCNC Integrationand MaintenanceManual
8520-6.4 9/SeriesCNC AMPReference Manual
8520-6.5 T-Line-9 Transfer LineQuick Start Guide
8520--6.6 9/Series CNCOCI Installation Manual
8520--6.7 9/Series CNCOCI API Developer’ s Guide
MCD-5.1 OfflineDevelopment System User’sManual
END OF CHAPTER
1.6
Related Publications
