{ABS} (Large Display)
Axis position in the machine coordinate system displayed in large
characters.
Figure 8.5
Results After Pressing {ABS} (Large Display) Softkey
PRGRAM A B S TARGET D T G AXIS
SELECT
E-STOP
ABSOLUTE[ MM ] (ACTIVE PROGRAM NAME)
X 0.000
Z 0.000
U -0.035
F 0.000 MMPM S 00
{ABS} (Small Display)
The axis position data in the machine coordinate system displayed for all
system axes in the active process (only available when more than 9 axis are
AMPed in the system, or more than 8 axis in the process for dual process
systems).
